| Brand Name : | Twisan |
| Model Number : | CPD30 |
| Certification : | ce & iso |
| Price : | FOBqingdao |
| Delivery Time : | within 7 days after receiving payment |
| Payment Terms : | T/T OR L/C |
| Supply Ability : | 500 sets |
3 ton Chinese electric forklift battery operated for sale
Main Technical Parameters
| Model | unit | CPD30 |
| power type | / | battery operated |
| operating mode | / | seat type |
| rated load | kg | 3000 |
| maximum lifting height | mm | 4185 |
| minimum turning radius | mm | 2200 |
| door frame tilt angle | deg | 6/12 |
| lift speed(full/empty) | mm/s | 280/450 |
| descend speed | mm/s | 480 |
| driving speed | km/h | 15 |
| load center distance | mm | 500 |
| turned way | / | electrical power steering |
| weight | kg | 4950 |
| lift motor power | kw | 13 |
| drive motor power | kw | 16.6 |
| braking system | / | hydtaulic brake |
| minimum ground clearance | mm | 145 |
| vehicle length | mm | 1260 |
| vehicle width | mm | 1220 |
| vehicle height | mm | 2215 |
| wheel base | mm | 1680 |
| tread base(front/rear wheels) | mm | 1000/980 |
| front tire | / | 28*9-15 |
| rear tire | / | 18×7-8 |
| battery | v/ah | 80600 |
| working hours per full charge | h | ≤8 |
| charging machine input voltage | v | 220v |
| every time charging time | h | 8 |
| climbing ability | % | ≤ 15 |
Brief specification
1.Mini electric forklift with small turining radius of 2200mm which
can pass through1220mm width aisle
2.No pollution,energy efficiency and environmental protection
3.Super low cost.Power consumption:8kwh per day.
4.Own 22 national patents,more competitive and imitation is
prohibited.
5.Different attachments for option.
Electic forklift application:
widely used in Railway stations, ports,airports,factories, warehouses,supermarkets,containers and so on .
Additional remarks
1.Spacious and comfortable room for maneuver,the driver according to their space,suitable adjustable of the seat, so that steering more comfortable.
2.The electric power steering,cornering control light,reliable,ease,in a narrow space with good maneuverability indeed.
3.The combination of ergonomic steering lever,reasonable and controllable lifting speed ,so smooth operations,improve work efficiency.
4.Vehicle compact,concise,easy manipulation,smooth,vision .
5.High quality and comfortable,adjustable front rear seats,enhanced driving comfort,a sense of stability.
6.Designed for total control of the switch(when the park closed),charing convenient and practical interface,can be charged under different circumstances.
7.Compact and practical models can be relaxed in a narrow space and flexible movement,reduce labor operating costs.
8.Safe and reliable protection roof rack,reducing operator stress,top mounted LED lights,turn signals,practical and beautiful.
9.Low cost to complete the arduous work
10.A variety of unique and innovative capability lets you get high efficiency output.
We are professional manufacturer of wheel loader and electric
forklift.We can produce wheel loader from 0.5T to 5T,and the
forklift from 0.5T to 5T.The toys of wheel loader and forklift is
going to be the market .Please pay your attention here!
Qingzhou Tuishan Heavy Industry Machinery Co., Ltd. is located in Qingzhou City which is a long history city with beautiful scenery and convenient transportation. Jiaoji Railway, Jining Expressway and 309 National Highway pass through Qingzhou with superior environment of geography, communications, information and humanity.
Our company occupies 40000 square meters and the covered area is 18000 square meters. We now have more than 400 workers including 8 senior engineers and 36 professional technicians. We have fixed assets more than 70millon RMB. We are the professional manufacturer with complete production facility and detection device in the field of engineer machinery business. Our main products contain ZLY series wheel loader(910H, 915BH, 918H, 918DH, 918E, 920E, 920B, 925D, 925F, 926D, 926F, 928D, 928F, 930F, 953), 5T, 6T, 7T, 8T, 10T truck crane and underground machine etc. We independent research and develop by adopting the advance technical from the similar machine in home and overseas and combining the structure principle of "Large and medium-sized loader".
Our products are with the characteristics of reasonable structure, attractive appearance, reliable performance, easy operating and convenient maintenance and so on. We get the clients' acceptance and praise due to the reliable performance, high efficiency operation and excellent service. More than 200 sales and service outlets cover all over the country.
